The SMA-10DL is a machine designed to separate Printed Circuit Boards which have been previously V-scored. It works either on traditional materials like FR4 as well as on Aluminium substrates (MCPCB).
Thanks to its unique design, the SMA-10DL can depanel both short and long boards, either bare or populated on one side only. In this last case, the maximum component height is 32 mm.
The alignment system allows three degrees of regulation. The first regulation is the height of the reference plan in relation to the cutting blades thanks to the use of a scaled knob. Then a guide allows to easily position the scored line aligned with the cutting blades and finally a mechanical reference assures the correct positioning of the panel. The guide can be easily adjusted to compensate different scoring depth.
The separated PCBs lay on a different plane also adjustable in height to allow a good positioning even in case of populated boards on both sides. The cutting blades have a diameter of 125 mm, and the lower blades are motorized with controlled speed adjustable from 0 to 120 rpm. The upper blades can be controlled in height, thus controlling the distance from the lower blades and adapt to different material thicknesses.
